Product series New
MODUS FSQ SMART
Floor-standing luminaire SMART
Standard price from:
On request
Floor-standing luminaire for direct-indirect lighting in two variants differing from each other in the way of control.
FSQ MIX - luminaire for continuous color temperature change, personal detection and lighting level control
FSQ SB - luminaire with constant color temperature 4000K and with lighting level control
Find out more about human centric lighting and tunable white in our MODUS TUNABLE LIGHT catalogue.
| Mounting method: | Free-standing | Protection class: | I | Type of control gear: | LED operating device current-controlled | Color rendering index CRI: | 80-89 | Light source type: | LED | Color temperature controllable (K): | Yes | Light outlet: | Direct/indirect | Nominal voltage (V): | 220...240 | Degree of protection (IP): | IP20 | Color temperature (K): | 4000, 2700...6500 |
| Rated lifetime L80/B50 (h): | 80000 | Dimming DALI: | Yes | Product category: | Floor luminaire | Optical system: | KN nanoprizmatic cover | Made in Czech republic: | Yes | Replaceability: | Removeable light source, replaceable ballast Removeable light source, replaceable ballast | Photobiological safety EN 62 471: | RG 0 | MacAdam binning: | SDCM 3 |
LoadingFilters
Effective luminous flux (lm)
System power (W)
Product name
Effective luminous flux (lm)
System power (W)
Color temperature (K)
FSQ6000RS3KNDI/SC
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 3000
FSQ6000RS4KNDI/SB
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 4000
FSQ6000RS4KNDI/SB/9005
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 4000
FSQ6000RS4KNDI/SB/9010
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 4000
FSQ6000RS4KNDI/SC
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 4000
FSQ6000RS4KNDI/SC/9003
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 4000
FSQ6000RS4KNDI/SC/9005
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 4000
FSQ6000RS4KNDI/SC2
Effective luminous flux (lm): 5800
System power (W): 52
Color temperature (K): 4000
FSQ6000RSKNDI/MIX
Effective luminous flux (lm): 6100
System power (W): 65
Color temperature (K): 2700...6500
FSQ6000RSKNDI/MIX/90
Effective luminous flux (lm): 5200
System power (W): 65
Color temperature (K): 2700...6500
FSQ6000RSKNDI/SMIX
Effective luminous flux (lm): 6100
System power (W): 65
Color temperature (K): 2700...6500
FSQ6000RSKNDI/SMIX/90
Effective luminous flux (lm): 6100
System power (W): 65
Color temperature (K): 2700...6500
FSQ8000RS3KNDI/SC
Effective luminous flux (lm): 8500
System power (W): 80
Color temperature (K): 3000
FSQ8000RS4KNDI/SB
Effective luminous flux (lm): 8500
System power (W): 80
Color temperature (K): 4000
FSQ8000RS4KNDI/SC
Effective luminous flux (lm): 8500
System power (W): 80
Color temperature (K): 4000
FSQ8000RS4KNDI/SC2
Effective luminous flux (lm): 8500
System power (W): 80
Color temperature (K): 4000
