Product series

MODUS QP

LED panel for surface installation

MODUS Q A
MODUS Q AMODUS Q A
MODUS Q BMODUS Q B
MODUS Q CMODUS Q C
MODUS Q DMODUS Q D
MODUS Q EMODUS Q E
třída ochrany I.PNG
220-240 v.png
11 L80_80000_h.jpg
en 62 471.png

Standard price from:

On request
Distribution network
Contacts

LED panel for special surface installation, installation is made by metal driver box, which is on back side of luminaire. By this installation there space 4 cm between luminaire and ceiling - luminaire looks like flying. Very interesting installation effect.

Body:

Eloxal aluminium frame (available also in white)



Optic:

Translucent acrylic layer

Opal cover



LED:

Mid Power LED

CRI 80 (CRI 90 on request)

2...warm white 2900K

3…cold white 3800K

5…daylight 5300K



Wiring:

LED current driver

ND – not dimmable (standard)

DALI – dimmable DALI

DIM - dimmable 1-10V DC

PHC - phase-cut dimming

Luminaire can be supplied with wireless Bluetooth control - more information here.



Version (body shape):

Q..A - square 600x600 mm

Q..B - rectangle 600x300 mm

Q..C - rectangle 1200x300 mm

Q..D - rectangle 1200x600 mm

Q..E - square 300x300 mm

Q..F - rectangle 1500x300 mm



Installation way:

Q - insulation class II, for recessed installation into a raster ceiling 600x600 or 625x625. Using accessories the panels can be also installed as pendant, surfaced or recessed into gypsum plasterboard ceiling

QP - insulation class I, for surface installation or recessed installation into a raster ceiling 600x600 or 625x625. Using accessories the panels can be also installed as pendant or recessed into gypsum plasterboard ceiling.



Note:

QD (QPD) - panel with a decorative motives



Size version:A
600x600 mm or 625x625 mm
B
600x300 mm
C
1200x300 mm
D
1200x600 mm
E
300x300 mm
F
1500x300 mm
Body material:Eloxal aluminium frame
Mounting method:Built-in, Pendant, Surface mountingProtection class:I
Type of control gear:LED operating device current-controlledColor rendering index CRI:80-89, 90-100
Light source type:LEDColor temperature controllable (K):Yes
Nominal voltage (V):220...240Degree of protection (IP):IP20, IP40
Color temperature (K):6500, 2900, 3800, 2700, 5300, 2700...6500Rated lifetime L80/B50 (h):80000
Dimming 1-10 V:YesDimming DALI:Yes
Optical system:KO
opal cover
Made in Czech republic:Yes
Replaceability:Removeable light source, replaceable ballast
Removeable light source, replaceable ballast
Photobiological safety EN 62 471:RG 0
MacAdam binning:SDCM 3
Show more...
LoadingLoading

Filters

Effective luminous flux (lm)

1700
12800

System power (W)

19
98
Product name
QP2A600/1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/1050DALIT
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/1050NDNZ
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/700DALIT
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/700NDNZ
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B1050DALIT
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B700NDNZ
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B700NDNZ/90
Effective luminous flux (lm): 3850
System power (W): 34
Color temperature (K): 2900
Length (mm): 596
Raster (mm): 600
QP2A600/B700NDNZ3
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A600/B700PHC
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2A625/1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2A625/1050DALI/90
Effective luminous flux (lm): 5450
System power (W): 50
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2A625/1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2A625/1050ND/90
Effective luminous flux (lm): 5450
System power (W): 50
Color temperature (K): 2900
Length (mm): 622
Raster (mm): 625
QP2A625/700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2A625/700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2A625/B1050DALIT
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2A625/B1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2A625/B700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 3000
Length (mm): 622
Raster (mm): 625
QP2B600/350DALI
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/350ND
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/350NDNZ3
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/500DALI
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/500DALIT
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/500ND
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/500NDNZ
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/B350DALI
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/B350ND
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2B600/B500ND
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 3000
Length (mm): 596
Raster (mm): 600
QP2C600/1050DALI
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/1050ND
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/1050NDNZ
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/700DALI
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/700DALIT
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/700ND
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/700ND/90
Effective luminous flux (lm): 3850
System power (W): 35
Color temperature (K): 2900
Length (mm): 1196
Raster (mm): 600
QP2C600/700NDNZ3
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/700PHC
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/B1050DALI
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/B1050ND
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/B700DALI
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/B700ND
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/B700NDNZ
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2C600/B700NDNZ/90
Effective luminous flux (lm): 3850
System power (W): 35
Color temperature (K): 2900
Length (mm): 1196
Raster (mm): 600
QP2C600/B700PHC
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2D600/1400DALI
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2D600/1400ND
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2D600/1400NDNZ
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2D600/2100DALI
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2D600/2100DALIT
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2D600/2100ND
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 3000
Length (mm): 1196
Raster (mm): 600
QP2E600/250DALI
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 3000
Length (mm): 296
Raster (mm): 600
QP2E600/250ND
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 3000
Length (mm): 296
Raster (mm): 600
QP2E600/700ND
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 3000
Length (mm): 296
Raster (mm): 600
QP2E600/B250DALI
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 3000
Length (mm): 296
Raster (mm): 600
QP2E600/B250ND
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 3000
Length (mm): 296
Raster (mm): 600
QP2E600/B250ND/90
System power (W): 9
Color temperature (K): 2900
Length (mm): 296
Raster (mm): 600
QP2E600/B700ND
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 3000
Length (mm): 296
Raster (mm): 600
QP2F600/1050DALI
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP2F600/1050ND
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP2F600/1400DALI
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP2F600/1400DALI/90
Effective luminous flux (lm): 6300
System power (W): 61
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP2F600/1400ND
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP2F600/B1400DALI
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP2F600/FS1050ND
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP2F600/FS1400ND
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 3000
Length (mm): 1496
Raster (mm): 600
QP3A600/1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/1050DALI/90
Effective luminous flux (lm): 5450
System power (W): 50
Color temperature (K): 3800
Length (mm): 596
Raster (mm): 600
QP3A600/1050DALINZ
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/1050DALINZ/90
Effective luminous flux (lm): 5450
System power (W): 50
Color temperature (K): 3800
Length (mm): 596
Raster (mm): 600
QP3A600/1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/1050NDNZ
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/700DALINZ
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/700ND/90
Effective luminous flux (lm): 3850
System power (W): 34
Color temperature (K): 3800
Length (mm): 596
Raster (mm): 600
QP3A600/700NDNZ
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/700NDNZ/90
Effective luminous flux (lm): 3850
System power (W): 34
Color temperature (K): 3800
Length (mm): 596
Raster (mm): 600
QP3A600/B1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/B1050DALINZ
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/B1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/B1050NDNZ3
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/B700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/B700DALI/90
Effective luminous flux (lm): 3850
System power (W): 34
Color temperature (K): 3800
Length (mm): 596
Raster (mm): 600
QP3A600/B700DALINZ
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/B700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A600/B700ND/90
Effective luminous flux (lm): 3850
System power (W): 34
Color temperature (K): 3800
Length (mm): 596
Raster (mm): 600
QP3A600/B700NDNZ
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A625/1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/1050DALI/BTC
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/1050ND/90
Effective luminous flux (lm): 5450
System power (W): 50
Color temperature (K): 3800
Length (mm): 596
Raster (mm): 600
QP3A625/1050NDNZ
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/1050SR
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/700DALI/90
Effective luminous flux (lm): 3850
System power (W): 34
Color temperature (K): 3800
Length (mm): 622
Raster (mm): 600
QP3A625/700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/700NDNZ3
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/700PHC
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3A625/B1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/B1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/B700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3A625/B700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3B600/350DALI
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B600/350ND
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B600/350NDNZ
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B600/500DALI
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B600/500ND
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B600/500NDNZ
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B600/B350DALI
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B600/B350ND
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 4000
Length (mm): 596
Raster (mm): 600
QP3B625/500ND
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 4000
Length (mm): 622
Raster (mm): 625
QP3C600/1050DALI
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/1050DALINZ3
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/1050ND
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/1050ND/90
Effective luminous flux (lm): 5200
System power (W): 50
Color temperature (K): 3800
Length (mm): 1196
Raster (mm): 600
QP3C600/1050NDNZ3
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/1050NDNZ3/90
Effective luminous flux (lm): 5200
System power (W): 50
Color temperature (K): 3800
Length (mm): 1196
Raster (mm): 600
QP3C600/700DALI
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/700DALI/90
Effective luminous flux (lm): 3850
System power (W): 35
Color temperature (K): 3800
Length (mm): 1196
Raster (mm): 600
QP3C600/700DALINZ
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/700ND
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/700NDNZ
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/700PHC
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/B1050DALI
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/B1050ND
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/B700DALI
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/B700ND
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/B700ND/90
Effective luminous flux (lm): 3850
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/C1050DALI
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3C600/C700NDNZ
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/1400DALI
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/1400DALI/BTC
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/1400ND
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/2100DALI
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/2100DALI/90
Effective luminous flux (lm): 10900
System power (W): 98
Color temperature (K): 3800
Length (mm): 1196
Raster (mm): 600
QP3D600/2100DALINZ/90
Effective luminous flux (lm): 10900
System power (W): 98
Color temperature (K): 3800
Length (mm): 1196
Raster (mm): 600
QP3D600/2100DALIT
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/2100ND
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/2100NDNZ
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/B1400DALIT
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/B1400ND
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3D600/B2100ND
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 4000
Length (mm): 1196
Raster (mm): 600
QP3E600/250DALI
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/250DALI/90
System power (W): 9
Color temperature (K): 3800
Length (mm): 296
Raster (mm): 600
QP3E600/250ND
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/700DALI
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/700DALI/90
Effective luminous flux (lm): 1700
System power (W): 23
Color temperature (K): 3800
Length (mm): 296
Raster (mm): 600
QP3E600/700ND
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/B250DALI
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/B250ND
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/B250ND/90
System power (W): 9
Color temperature (K): 3800
Length (mm): 296
Raster (mm): 600
QP3E600/B700DALI
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/B700ND
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3E600/C250ND
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 4000
Length (mm): 296
Raster (mm): 600
QP3F600/1050DALI
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/1050DALI/BTC
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/1050ND
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/1400DALI
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/1400DALI/BTC
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/1400DALINZ
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/1400ND
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/1400ND/90
Effective luminous flux (lm): 6300
System power (W): 61
Color temperature (K): 3800
Length (mm): 1496
Raster (mm): 600
QP3F600/500ND
Effective luminous flux (lm): 2600
System power (W): 24
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/B1050DALI/BTC
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP3F600/B1400ND
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 4000
Length (mm): 1496
Raster (mm): 600
QP5A600/1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A600/1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A600/1050NDNZ
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A600/1050NDNZ3
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A600/700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A600/700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A600/700NDNZ
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A600/B1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5A625/1050DALI
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 622
Raster (mm): 625
QP5A625/1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 622
Raster (mm): 625
QP5A625/1050ND/90
Effective luminous flux (lm): 5450
System power (W): 50
Color temperature (K): 5300
Length (mm): 622
Raster (mm): 625
QP5A625/1050NDNZ3
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 622
Raster (mm): 625
QP5A625/700DALI
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 5700
Length (mm): 622
Raster (mm): 625
QP5A625/700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 5700
Length (mm): 622
Raster (mm): 625
QP5A625/B1050ND
Effective luminous flux (lm): 6400
System power (W): 50
Color temperature (K): 5700
Length (mm): 622
Raster (mm): 625
QP5A625/B700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 5700
Length (mm): 622
Raster (mm): 625
QP5B600/350ND
Effective luminous flux (lm): 2000
System power (W): 19
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5B600/500DALI
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5B600/500ND
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5B600/B500ND
Effective luminous flux (lm): 2800
System power (W): 26
Color temperature (K): 5700
Length (mm): 596
Raster (mm): 600
QP5C600/1050DALI
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5C600/1050DALI/90
Effective luminous flux (lm): 5200
System power (W): 50
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5C600/1050ND
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5C600/700DALI
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5C600/700ND
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5C600/700ND/90
Effective luminous flux (lm): 3850
System power (W): 35
Color temperature (K): 5300
Length (mm): 1196
Raster (mm): 600
QP5C600/B1050ND
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5C600/B700ND
Effective luminous flux (lm): 4500
System power (W): 35
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5D600/1400DALI
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5D600/1400DALI/BTC
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5D600/1400ND
Effective luminous flux (lm): 9000
System power (W): 68
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5D600/1400ND/90
Effective luminous flux (lm): 7650
System power (W): 68
Color temperature (K): 5300
Length (mm): 1196
Raster (mm): 600
QP5D600/2100DALI
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5D600/2100DALI/9010
Effective luminous flux (lm): 10900
System power (W): 98
Color temperature (K): 5300
Length (mm): 1196
Raster (mm): 600
QP5D600/2100ND
Effective luminous flux (lm): 12800
System power (W): 98
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5D600/2100ND/90
Effective luminous flux (lm): 10900
System power (W): 98
Color temperature (K): 5700
Length (mm): 1196
Raster (mm): 600
QP5E600/250ND
Effective luminous flux (lm): 700
System power (W): 9
Color temperature (K): 5700
Length (mm): 296
Raster (mm): 600
QP5E600/700ND
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 5700
Length (mm): 296
Raster (mm): 600
QP5E600/B700ND
Effective luminous flux (lm): 2400
System power (W): 23
Color temperature (K): 5700
Length (mm): 296
Raster (mm): 600
QP5F600/1050ND
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 5700
Length (mm): 1496
Raster (mm): 600
QP5F600/1400DALI
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 5700
Length (mm): 1496
Raster (mm): 600
QP5F600/1400ND
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 5700
Length (mm): 1496
Raster (mm): 600
QP5F600/1400ND/90
Effective luminous flux (lm): 6300
System power (W): 61
Color temperature (K): 5700
Length (mm): 1496
Raster (mm): 600
QP5F600/B1050ND
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 5700
Length (mm): 1496
Raster (mm): 600
QP5F600/B1400ND/90
Effective luminous flux (lm): 6300
System power (W): 61
Color temperature (K): 5700
Length (mm): 1496
Raster (mm): 600
QP5F600/C1050DIM
Effective luminous flux (lm): 5700
System power (W): 47
Color temperature (K): 5700
Length (mm): 1496
Raster (mm): 600
QP6A600/1050ND/90
Effective luminous flux (lm): 5450
System power (W): 50
Color temperature (K): 6500
Length (mm): 596
Raster (mm): 600
QP6A600/700ND
Effective luminous flux (lm): 4500
System power (W): 34
Color temperature (K): 6500
Length (mm): 596
Raster (mm): 600
QP6A600/700ND/90
Effective luminous flux (lm): 3850
System power (W): 34
Color temperature (K): 6500
Length (mm): 596
Raster (mm): 600
QP6C600/1050ND
Effective luminous flux (lm): 6100
System power (W): 50
Color temperature (K): 6500
Length (mm): 1196
Raster (mm): 600
QP6F600/1400DALI
Effective luminous flux (lm): 7400
System power (W): 61
Color temperature (K): 6500
Length (mm): 1496
Raster (mm): 600
QP6F600/1400ND/90
Effective luminous flux (lm): 6300
System power (W): 61
Color temperature (K): 6500
Length (mm): 1496
Raster (mm): 600
Show all versions

Office building of HAGER company

MODUS SPMI + MODUS QP

Detail reference

Shopping mall Prague - Chodov

MODUS Q

Detail reference

Czech radio Pilsen

MODUS QP, UQ,UQRAM

Detail reference
OTERA - Panel med trykk-Medium-14.jpg

Office building

MODUS SKY

Detail reference
Zobrazit další reference
Pendant mounting of luminaires

Pendant mounting of luminaires

Wire suspensions sets

QVESTRAM

QVESTRAM

Aluminium frame for recessed installation

 Back to product list

We are here to help

We'll advise you all, we have outstanding support.
Lighting calculations

Lighting calculations

Do you need to calculate the lighting?

LDT files

LDT files

Do you need LDT data for your project?

Product support

Product support

Do not know what kind of lighting is best for you?

Connection diagrams

Connection diagrams

Do not you know how to conect luminaires properly?

Contact
