Product series MODUS MEGAL V4
MODUS MEGA LED 1220mm, 2x LED , 840, prizmatic PC cover, pendant, 2x600 mA non-dimmable, with gear box
Metal industrial luminaire with IP65 - eco
Code: MEGAL4M4PCNV4/1200ND
EAN: 8596099054588
Luminaire properties
| Product category: | High bay luminaire | Effective luminous flux (lm): | 21000 | System power (W): | 173 | Luminaire efficacy (lm/W): | 121 |
| Rated lifetime L70/B50 (h): | 100000 | Rated lifetime L80/B50 (h): | 80000 | Degree of protection (IP): | IP65 | Mounting method: | Pendant | Color housing: | White |
| Impact strength: | IK10 | Ball-proof: | Yes | Material housing: | Steel | Light source included: | Yes | Fire resistance D: | Yes |
| Rated ambient temperature (°C): | -25...+45 | Made in Czech republic: | Yes |
Light source
| Light source type: | LED | Color temperature (K): | 4000 | Color rendering index CRI: | 80-89 | Replaceability: | Removeable light source, replaceable ballast |
Optical system
| Optical system: | PCN | Reflector: | High-gloss | Anti-glare limiting UGR: | 22 | Light sharing: | Symmetric |
| Material reflector: | Aluminium |
Dimensions
| Length (mm): | 1224 | Width (mm): | 357 | Height/depth (mm): | 90 | Weight (kg): | 11 |
Electrical values
| Protection class: | I | Voltage type: | AC | Type of control gear: | LED operating device current-controlled | Nominal voltage (V): | 220...240 |
| Control gear included: | Yes | No dim function: | Yes |
LoadingFilters
Effective luminous flux (lm)
System power (W)
Product name
Effective luminous flux (lm)
System power (W)
Color temperature (K)
Optical system
Length (mm)
Ball-proof
MEGAL2M4KNV4/600ND
Effective luminous flux (lm): 12000
System power (W): 87
Color temperature (K): 4000
Optical system: KN
Length (mm): 1224
MEGAL2M4PCNV4/600DALI
Effective luminous flux (lm): 10500
System power (W): 87
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL2M4PCNV4/600ND
Effective luminous flux (lm): 10500
System power (W): 87
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL2M4V4/600ND
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGAL4M4KNV4/1200ND
Effective luminous flux (lm): 24000
System power (W): 173
Color temperature (K): 4000
Optical system: KN
Length (mm): 1224
MEGAL4M4PCNV4/1200DALI
Effective luminous flux (lm): 21000
System power (W): 173
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL4M4PCNV4/1200ND
Effective luminous flux (lm): 21000
System power (W): 173
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL4M4V4/1200DALI
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGAL4M4V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGAL4M5V4/1200DALI
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
MEGAL4M5V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
MEGALW2M4PCOV4/600ND
Effective luminous flux (lm): 10800
System power (W): 87
Color temperature (K): 4000
Optical system: PCO
Length (mm): 1224
MEGALW2M4PCV4/600DALI
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 4000
Optical system: PC
Length (mm): 1224
MEGALW2M4PCV4/600ND
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 4000
Optical system: PC
Length (mm): 1224
MEGALW2M4V4/600DALI
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW2M4V4/600ND
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW2M4V4/600ND/90
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW2M5PCOV4/600ND
Effective luminous flux (lm): 10800
System power (W): 87
Color temperature (K): 5700
Optical system: PCO
Length (mm): 1224
MEGALW2M5PCV4/600DALI
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 5700
Optical system: PC
Length (mm): 1224
MEGALW2M5PCV4/600ND
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 5700
Optical system: PC
Length (mm): 1224
MEGALW2M5V4/600ND
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
MEGALW4M4PCOV4/1200DALI
Effective luminous flux (lm): 21500
System power (W): 173
Color temperature (K): 4000
Optical system: PCO
Length (mm): 1224
MEGALW4M4PCOV4/1200ND
Effective luminous flux (lm): 21500
System power (W): 173
Color temperature (K): 4000
Optical system: PCO
Length (mm): 1224
MEGALW4M4PCV4/1200ND
Effective luminous flux (lm): 26200
System power (W): 173
Color temperature (K): 4000
Optical system: PC
Length (mm): 1224
MEGALW4M4V4/1200DALI
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW4M4V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW4M5PCV4/1200ND
Effective luminous flux (lm): 26200
System power (W): 173
Color temperature (K): 5700
Optical system: PC
Length (mm): 1224
MEGALW4M5V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
